MerCruisers are inboard engines produced by marine engine company Mercury Marine. MerCruiser produces a number of different sized inboard motor that vary in performance and purpose. The recommended oil for all Mercruisers, from the 3-liter to the 8.2-liter high output, is SAE 20W-40 MerCruiser full synthetic engine oil.
Feb 08, 2013 As I read it the serial no. For model year 2003 starts with 0M365640 for 4.3 MPI Alpha One models and 0M365680 for Bravo models. Model year 2004 starts with 0M656797 for 4.3 MPI Alpha One models and 0M655926 for Bravo models. Find your MerCruiser parts by serial number just by clicking back, and use your serial number information to find the OEM parts you need. Locating MerCruiser Serial Number Tags Engine Serial Number: The serial number tag is located near the starter, by the flywheel housing;. MerCruiser Inboard/Outdrive Model Identification Guide Locating MerCruiser Serial Number Tags Engine Serial Number: The serial number tag is located near the starter, by the flywheel housing; or, on the rocker arm or flame arrestor cover.
Features
MerCruiser inboard engines are built to be a part of a sterndrive system. Sterndrive systems combine both aspects of inboard and outboard motors. A boat that is powered by sterndrive will have an inboard motor that is directly connected with an outboard propeller.
History
MerCruisers were first introduced to the public in 1961 at the Chicago Boat Show. These engine were revolutionary because they were the first inboard engines to offer more than 100 horsepower.
Considerations
It is important to remember that while all MerCruiser have the same recommended oil, they do not all have the same recommended fuel. Some MerCruiser engines require regular unleaded gasoline, while others require premium unleaded. Mercruiser owners should be aware of the recommended fuel for their engine.
More Articles
Mercury produced the Alpha One, Bravo One, Bravo Two, and Bravo Three outdrives beginning in 1972. Later known as the Generation I Alpha One, this outdrive was replaced by the Alpha One Generation II outdrive for the 1984 model year. Production on the 'Gen II' Alpha One continues as of 2011. Because the Alpha One outdrives were limited to relatively low-horsepower applications -- 300 horsepower or less -- Mercury introduced the Bravo series of outdrives in 1986 for engines of up to 600 horsepower and speeds of up to 100 mph.
Alpha One Generation I Outdrive
The Mercruiser Alpha One Generation I outdrive dating from 1972 through 1983 has a square upper gearcase cap with an eye attached to the 4 1/2-by-4 1/2-inch cap. The Alpha One dating from 1984 to 1992 has the same size upper gear case but lacks the lifting eye on top of the gear case cap. The Alpha One Generation I outdrive is limited to engines of 300 horsepower or less.
Alpha One Generation II Outdrive
The Alpha One Generation II upper gear case has a rectangular top cap that's 4 1/2 by 6 1/2 inches, 2 inches larger than the Generation I outdrive. The 'Gen II' Alpha One also does not offer a lifting ring on top of the drive cap. The cap has a lifting notch at the center-rear that does not extend as far across the top cap as the rear bolt holes. Like the Generation I Alpha One outdrive, the Generation II Alpha One is limited to applications of 300 horsepower or less.
Bravo One and Bravo Two
Mercruiser Serial Number Year Lookup
The Bravo One outdrive, for a single engine application, has a lifting notch at the center of the rear of the top cap that extends to the rear bolt holes, almost halfway across the 4 1/2-by-6-inch cover. The Bravo Two outdrive, while physically similar, is not found on engines of greater than 450 horsepower or boats that operate at speeds of greater than 55 mph. For lower-speed or lower-horsepower applications, a Mercury dealer can identify the drive by its serial number.
Bravo Three Outdrive
The Bravo Three outdrive overcomes the tendency of Mercury outdrives to pull the boat to the left. Mercury drives rotate counterclockwise. The torque from this rotation pulls a boat somewhat to port along its course when moving forward. When backing, the torque vigorously pulls the boat to port, even after the engine stops. The Bravo Three outdrive uses a propeller shaft-within-a-shaft driving a twin propeller. The outer propeller shaft turns the propeller nearest the outdrive counterclockwise. The inner propeller shaft -- the shaft-within-a-shaft -- turns the propeller farthest from the outdrive clockwise. These 'counterrotating' propellers cancel out each others' torque to eliminate pull to the left or the right when the boat moves.
References
Mercruiser Sterndrive Serial Number Lookup
- Mercruiser Service Manual Number 3A -- Sterndrives; Mercury Marine
- Mercruiser Service Manual Number 11 -- Bravo Sterndrives; Mercury Marine
About the Author
Mercruiser Outdrive Serial Number
Will Charpentier is a writer who specializes in boating and maritime subjects. A retired ship captain, Charpentier holds a doctorate in applied ocean science and engineering. He is also a certified marine technician and the author of a popular text on writing local history.
